Calpeda NMD 32/210C/A End Suction Threaded Pump 415V

SKU
NMD32/210C/A
MRRP £1,736.00 + VAT Our price £1,215.00 (+ VAT) Incl. VAT: £1,458.00
Order within
Hours
Mins
Secs
for next day delivery i

Calpeda NMD 32/210C/A close coupled, centrifugal end suction pump with back-to-back impellers and screwed (threaded) connection, and 5.5kW (7.5HP) 415V 3Ph 50Hz motor.

Calpeda NM and NMD threaded pump range are close-coupled, centrifugal pumps with electric motor and extended shaft directly connected to the pump.


NM:   single-impeller
NMD:  two back-to-back impellers (with axial thrust balancing).

The NM and NMD threaded pump range are suitable for the following applications:

  • Clean liquids without  non-aggressive abrasives ( solids content up to 0.2%)
  • Mains water supply
  • Heating, air-conditioning, cooling and circulation plants
  • Civil and industrial applications
  • Fire fighting applications
  • Irrigation
More Information
SKU NMD32/210C/A
Manufacturer Calpeda
Manufacturers Warranty 1 Year
Weight 70.0 Kg
Dimensions 550mm Deep x 258mm Wide x 365mm High
Motor Size (kW/W) 5.5 kW
Voltage 415V 3Ph 50Hz
Max Flow 12 m3/hr
Max Head 84m
Material Cast Iron
