Lowara e-SHE 80-250/55/P45VSNA End Suction Centrifugal Pump 400v

SKU
101863740
MRRP £8,517.00 + VAT Our price £5,961.90 (+ VAT) Incl. VAT: £7,154.28
Order within
Hours
Mins
Secs
for next day delivery *i

* Available where Guaranteed Stock Icon Appears Below

Lowara's replacement to the SHE/SHS series

Lowara e-SH series single impeller, centrifugal, end suction pumps suitable for many applications that require constant or variable duty points in a cost saving operation. Lowara e-SH pumps are manufactured entirely in corrosion resistant AISI 316 stainless steel which makes them suitable for handling water as well as non aggressive or moderately aggressive fluids.

The pumps are equipped with interchangeable mechanical seals, IE3 efficiency motors, and are designed with aback pull-outconfiguration, which means the impeller, adapter and motor can be extracted without disconnecting the pump body from the piping system.

Some suitable applications include: process cooling/heating, air conditioning and ventilation systems, liquid transfer, pressure boosting, irrigation and washing/cleaning.

The e-SH pumps come with the standard extended shaft, however the following are available in the following constructions, Please contact the sales team on 0800 112 3134 if you require one of these versions:

  • Stub shaft
  • Bare shaft
  • Frame mounted

Specifications

  • Maximum liquid temperature: 120C
  • Delivery: Up to 240 m/h
  • IP55 Protection
  • Insulation class: F

Materials

  • Pump Body: AISI 316L Stainless Steel
  • Impeller: AISI 316L Stainless Steel
  • Mechanical Seal: Carbon/Ceramic/FP
More Information
SKU 101863740
Manufacturer Lowara
Manufacturers Warranty 2 Years
Weight 98.0 Kg
Dimensions 383mm (w) x 480mm (h) x 630mm (l)
Inlet Dimension DN100 Flanged
Discharge Dimension DN80 Flanged
Motor Size (kW/W) 5.5kW
Voltage 415V 3Ph 50Hz
RPM 1450rpm
Max Flow 125m3/hr
Max Head 20m
Max Temperature 120°C
Material Stainless Steel
Seal Type Ceramic / Carbon / FKM
Impeller Material Stainless Steel
